luminaire élevé de lampe de baie de la puce LED de lumileds 3030 de lumen 20030

Description du produit

produit similaire \ n ZGSM UFO SERIES ZGSM HB SERIES \ n

\ n \ n haute lumen 200W lumileds 3030 puce LED luminaire haute baie \ n

1. Wide power range: 40W~480W

2. Special circuit design, single LED’s damage won't affect others' normal work

3. Modular design for easy installation, replacement and maintenance.

4. High Lumen output up to 165lm/w with high quality LED chips

5. Variety applications with different mounting Accessories

6. Multiple lighting control options are available, e.g. DALI, 1-10V, Motion sensor

7. Designed to last at least 100,000 hours at L70

8. Multiple lighting distributions available

9. UL/ DLC/ SAA/ CB/ CE/ RoHS/ IK10 /IP66 /LM79

10. 7 years limited warranty available.

Overview

Product Benefits

LED LUMINOUS SOURCE

The ZGSM H-Series LED High Bay Lights are utilizing LUXEON TX luminous source, providing excellent lumen output - up to 110 LPW, long-lasting stability and splendid sight.

Each LUXEON TX owns eletrostatic protection component, maximally avoid the damage of electrostatic.

More information about the LUXEON TX and solid-state lighting technologies can be found at

LED DRIVER

Full Range of ZGSM H-Series LED Street Lights are Utilizing MEANWELL HLG Series high-end driver, optimal operation stability, lifespan and performance.

More information about the MEANWELL HLG and LED driver technologies, please visit

ZGSM 3RD GENERATION LED MODULE

Exquisite design with powerful thermal performance, as well as high reliable waterproof rating.

XTREME LUMINAIRE DESIGN

Equipped with exceptional ZGSM 3rd generation LED module, the H-Series LED High Bay Lights give best luminous output, stability and extra long life. H-Series LED High Bay Lights are intended to build the most cost-performance luminaires ever.

ZGSM completed the R&D independently, and reserve all related patents for H-Series LED High Bay Lights.

Easy assemble/disassemble, neat wiring & connection, up to 110 LPW luminous efficiency, IP66 and IK10 Rated, 90%+ driver efficiency, over then 100,000 hours operation life and 5 years warranty.

More information about ZGSM H-Series LED High Bay Lights and LED lighting technologies at

\ n \ n \ n

Specification

\ n

Specifications
Model	ZGSM-GCD200H5
LED Brand	Philips Lumileds 3030
Driver Brand	Meanwell HLG series
Norminal Wattage	200W
LED Module Quantity	4 modules
Input Voltage	100-240/277VAC
Power Efficiency	>90%
Power Factor	>0.95
Lamp Rated Luminous Efficiency	>125 lm/w
Lamp Rated Lumen output	25,000 lm (Lumen tolerance +/- 5%)
Color Rendering Index	Ra>70
Color Temperature	3000K, 4000K, 5000K or 5700K
Photometric Type	60,90,110 degrees
Optimal Operating Temperature	25℃
Storage Temperatures	‘-40℃~+70℃
Working Environment	Between-40°C~+50°C, 10%~90%RH
Total Harmonic Distortion	< 10%
Lumen Maintenance	> 75,000 hours -L70, @25 ºC (77 ºF)
Body and Shell Materials	Anodized Aluminum
IP Rating	IP66 with test report
IK Rating	IK10 with test report
Certification	CE, ROHS, IOS9001, ISO14001, LM80
Optional Function	1-10V DC or PWM Signal or Resistance Dimming
Optional Function	Timer/Photocell Control
Warranty	7 years

Packing Details
Fixture Dimension	512 x340 x156 mm
Fixture Weight	6.0 kg /13.2 lbs
Packing Dimension	560 x365 x160 mm
Packing Weight	7.0 kg /15.4 lbs
